PARTS LIST RAILROAD TOILET MODEL 200000-APF
|
PART NO. DESCRIPTION 100100-A BOWL WITH SPLASH RESTRICTOR 100105 PLENUM PLASTIC BOWL MOUNT-ORANGE 199101 VACUUM VENT 1" WITH MOUNTING PLATE 199200A MOUNTING FRAME W/ FLANGE, ALUMINUM, 2 RQD. (P/N 200000 DOES NOT HAVE FLANGES) 199500-APF FILTER, SSTL, ENCLOSED (To replace Part Number 199500-A) 199501-PF HOSE, PUMP TO FILTER WITH FITTINGS (To replace Part Number 199501) 199700 SEAT, SOLID PLASTIC, OPEN FRONT 200100 TANK, RIGHT HAND ORANGE 199600-1 SEAL ONLY FOR CVR 72" 200351-PF DIAPHRAGM, PUMP (To replace Part Number 200351) 200355-PF PLATE SET, PUMP, DIAPHRAGM MOUNTING (To replace Part Number 199500-A) 200356-SPF HANDLE AND GRIP, ALUM. – ORANGE GRIP (To replace Part Number 200356-S) 200358-PF ARM, PUMP #200358 (To replace Part Number 199500-A) 200358-1 PIN, ARM TO DIAPHRAGM STL CAD II 200363 SLIDER SEAL ASSEMBLY, HANDLE TO COVER ALUM 199362-PF HOSE TO PUMP, OUTLET TO BOWL & FILTER WITH FITTINGS 18.5" (To replace Part Number 199500-A) 200400-PF PUMP, COMPLETE ASSEMBLY (To replace Part Number 200400) 200401-PF PUMP MOUNTING BRACKET (To replace Part Number 200401) 200600-APF COVER PLATE 7 SEAL ONLY SSTL. (To replace Part Number 199500-A) 200600-BPF COVER PLATE & SEAL ASSY, SSTL INCLUDES: 100100-A, 100105, 200400, 200356-S, 200361-S, 200362, 200600-A, 200360-A, 199700 200800 SLIDE VALVE 200803 CLAMP, 4”, BAND SSTL, SLIDE VALVE MOUNTING 200804 HOSE, 4”, SLIDE VALVE MOUNTING 200901 FLOOR FLANGE SEAL, RUBBER, TOILET MOUNTING 200902 FLOOR FLANGE - ABS 4x3, TOILET MOUNTING |
|
|
